UAV Infrared Imaging

Airborne IR Optics Solutions for UAVs, Drones & Loitering Munitions

凭借数十年耕植于无人飞行器行业长波红外和中波红外镜头的知识和经验，Ophir已在该领域赢得了全球领先的设计和制造商声誉。 W我们开发并交付装备有各种定焦、电动调焦和连续变焦镜头的红外复杂镜头组件，支持无人飞行器中波红外和长波红外成像，

我们有各种镜头满足您的一切需求

Ophir为军事、安防和新兴无人飞行器应用提供适用于无人飞行器有效载荷的红外成像全局解决方案。
我们的内部研发团队与OEM国防客户合作，并配合探测器制造商，开发并设计符合无人飞行器有效载荷平台的尺寸重量和功率（SWAP）限制条件的产品，并以无与伦比的光学性能享誉全球。

产品特征

适用于微型万向节的小尺寸镜头
超轻型变焦和定焦镜头
高光学性能
低功耗
专为无人飞行器有效载荷、无人机和手持装备应用而设计
高耐久性或硬碳低反射（LRHC）增透膜
快速视场切换
在连续变焦的整个变焦过程中F#保持不变
精准的光轴一致性
必要时采用折叠光学技术
兼容多种主要的中波红外和长波红外探测器
衍射极限的光学设计
无热化补偿
整个变倍范围内保持齐焦性
预设的离散光学变焦位置
通过RS 485或RS 232控制CPU

Resources

Webinar: FoldIR Next Generation Infrared Optics for Aerial Superiority (31:18)

MWIR Imaging Lenses for UAV Applications

描述	特征
LightIR 10-135 mm f/3.6 Motorized MWIR Zoom Imaging Lens	Meets low SWaP demand with long EFL Efficient folded optics design for max. volume use Designed for MWIR 10 μm pitch 640x512 sensors Ideal for mini/ micro tactical payloads	LightIR 10-135 mm f/3.6 Motorized MWIR Zoom Imaging Lens
FoldIR 16-180mm f/3.6 10µm VGA MWIR Zoom Lens	Meets low SWaP demand with long EFL Efficient folded optics design for max. volume use Designed for MWIR 10 μm pitch 640x512 sensors Ideal for mini/ micro tactical payloads	FoldIR 16-180mm f/3.6 10µm VGA MWIR Zoom Lens
LightIR 18-225 mm f/3.6 Motorized MWIR Zoom Imaging Lens	Weight 305g Dimensions Ø63 x 84.6mm Detection range 15.5km Designed for MWIR 10µm VGA detectors	LightIR 18-225 mm f/3.6 Motorized MWIR Zoom Imaging Lens
LightIR 18-225 mm f/4.0 Motorized MWIR Zoom SXGA Imaging Lens	Efficient compact optics design for max. volume use Designed for MWIR 10 µm SXGA and 15 µm VGA Detectors Ideal for mini/micro tactical payloads Detection range exceeds 16 km	LightIR 18-225 mm f/4.0 Motorized MWIR Zoom SXGA Imaging Lens
LightIR 20–275mm f/5.5 MWIR Motorized Continuous Zoom Lenses	Smallest, most lightweight continuous zoom lens on the market Long-range capabilities of up to 14.9 km detection range Unique optomechanical design and focus movement High-durability and low reflection hard-carbon 3-5 µm wavelength AR coatings	LightIR 20–275mm f/5.5 MWIR Motorized Continuous Zoom Lenses
FOLDIR 25-275 mm f/5.5 Low-SWaP Cont. Zoom Lens	Weighs 302gr Efficient folded optics design for minimum volume use with total volume size of 107mm x 101.5mm x 96mm including detector Designed for MWIR 15μm VGA detectors Detection range exceeds 14.5km*	FOLDIR 25-275 mm f/5.5 Low-SWaP Cont. Zoom Lens
FoldIR 30-450mm f/3.4 Motorized MWIR Zoom SXGA Imaging Lens	Meets low SWaP demand with long EFL Efficient folded optics design for max. volume use Designed for MWIR 10 μm pitch 640x512 sensors Ideal for mini/ micro tactical payloads	FoldIR 30-450mm f/3.4 Motorized MWIR Zoom SXGA Imaging Lens
FoldIR 40-450 mm f/3.6 Motorized MWIR Zoom VGA Imaging Lens	Meets low SWaP demand with long EFL Efficient folded optics design for max. volume use Designed for MWIR 10 μm pitch 640x512 sensors Ideal for mini/ micro tactical payloads	FoldIR 40-450 mm f/3.6 Motorized MWIR Zoom VGA Imaging Lens
FoldIR 28-850 mm f/5.5 Motorized MWIR Zoom SXGA Imaging Lens	3 to 5 μm MWIR spectral range Compatible with High Definition 1280 x1024 detector format with 15 μm pixel pitch Folded design Tight boresight retention	FoldIR 28-850 mm f/5.5 Motorized MWIR Zoom SXGA Imaging Lens
SupIR 10-135mm f/1.8 Motorized Cont. Zoom MWIR 5μm SXGA Imaging Lenses	Meets low SWaP demand with long EFL Efficient folded optics design for max. volume use Designed for MWIR 10 μm pitch 640x512 sensors Ideal for mini/ micro tactical payloads	SupIR 10-135mm f/1.8 Motorized Cont. Zoom MWIR 5μm SXGA Imaging Lenses
FoldIR 50-1350 mm f/5.5 Motorized MWIR Zoom SXGA Imaging Lens	Longest focal length and zoom ratio Designed for UAV payloads Detection range >25km Unique folded optic design	FoldIR 50-1350 mm f/5.5 Motorized MWIR Zoom SXGA Imaging Lens

LWIR Imaging Lenses for UAV Applications

描述	特征
SupIR 15-60 mm f/1.4 LWIR Motorized Zoom Imaging Lens	Advanced technologies for the highest performance long wave focal planes LWIR High-durability and hard-carbon AR coatings for 8-12 µm Passive athermalization with the highest imaging performance from -32 to +80°C Compatible with 12 & 17 μm pixel pitch, 640x480 VGA format LWIR cameras	SupIR 15-60 mm f/1.4 LWIR Motorized Zoom Imaging Lens
LightIR 15-75 mm f/1.2 LWIR Motorized Zoom Imaging Lens	Most lightweight, compact, continuous zoom lenses on the market at 320 g Ideal for low-SWaP applications Optimized for 10-12 micron pixel size uncooled LWIR cameras Maintains sharp focus over the entire motorized 15-60 mm zoom range	LightIR 15-75 mm f/1.2 LWIR Motorized Zoom Imaging Lens
SupIR 7.5 mm f/1.4 Fixed 1-FOV LWIR Imaging Lens	Advanced technologies for the highest performance long wave focal planes LWIR Hard-carbon AR coating for 8-12 µm Passive athermalization with the highest imaging performance from -40 to +80°C Compatible with 12 & 17 μm pixel pitch, 640x480 VGA format LWIR cameras	SupIR 7.5 mm f/1.4 Fixed 1-FOV LWIR Imaging Lens
SupIR 13.6 mm f/1.0 Fixed 1-FOV LWIR VGA Imaging Lens	Advanced technologies for the highest performance long wave focal planes LWIR High-durability and hard-carbon AR coatings for 8-12 µm Passive athermalization with the highest imaging performance from -40 to +85°C Compatible with 12 μm pixel pitch, 1024x768 XGA format LWIR cameras	SupIR 13.6 mm f/1.0 Fixed 1-FOV LWIR VGA Imaging Lens
SupIR 19 mm f/1.1 Fixed 1-FOV LWIR XGA Imaging Lens	Advanced technologies for the highest performance long wave focal planes LWIR hard-carbon AR coating for 8-12 µm Passive athermalization with the highest imaging performance from -40 to +80°C Compatible with 12 μm pixel pitch, 1024x768 XGA format LWIR cameras	SupIR 19 mm f/1.1 Fixed 1-FOV LWIR XGA Imaging Lens
SupIR 25 mm f/1.2 Fixed 1-FOV LWIR XGA Imaging Lens	Advanced technologies for the highest performance long wave focal planes LWIR High-durability and hard-carbon AR coatings for 8-12 µm Passive athermalization with the highest imaging performance from -40 to +80°C Compatible with 12 μm pixel pitch, 1024x768 XGA format LWIR cameras	SupIR 25 mm f/1.2 Fixed 1-FOV LWIR XGA Imaging Lens

SWIR Imaging Lenses for UAV Applications

	描述	特征
	SWIR & NIR 25-250mm f/5.5 (NFOV) f/4.0 (WFOV) Motorized Continuous Zoom Imaging Lenses	Meets low SWaP demand with long EFL Efficient folded optics design for max. volume use Designed for MWIR 10 μm pitch 640x512 sensors Ideal for mini/ micro tactical payloads		SWIR & NIR 25-250mm f/5.5 (NFOV) f/4.0 (WFOV) Motorized Continuous Zoom Imaging Lenses
